Single Phase Induction Based Copper Melting Furnace

Product Description

• Perfect Homogeneous mixing due to auto stirring effect for increased productivity and perfect alloying.
• Economical, Efficient and Simple in Operation.
• Energy saving flameless device and also 80% income tax depreciable.
• Does not affect room temperature. Can also work in a/c showrooms.
• Heat and power loss reduced.
• Works on Single Phase connection

• Technology: IGBT Based.
• Power Supply & Voltage: Single Phase 230 Volts A/C.
• Absorbed Power: 4 KW/H.
• Capacity of Crucible: 500 Gms. Copper.
• Maximum Temperature & Type: 1200⁰ Degrees, "K" Type.
• Melting Time: 6 to 8 Minutes.
• Cooling Water Temperature: 20⁰ to 35⁰ Degrees.
• Water Pressure & Flow: 3 Bar, 3 Litres/Minute.
• Machine With Chiller Weight: Approx 80 Kgs.
• Machine with Chiller Size (LxWxH): Approx 88 x 88 x 96 (cms).
